Product Information
The SDE-3 fuses vintage digital character and wide-ranging versatility into one unique and inspiring BOSS compact pedal. Experience the genuine sound and core features of the Roland SDE-3000, an iconic ’80s-era rackmount delay favored by some of the most influential guitarists of all time. Flow into any creative setup with a slate of modern features. And twist the powerful Offset control to explore an array of colorful dual-delay textures.
Features
- The iconic character of the Roland SDE-3000 rackmount delay in a BOSS compact pedal
- Beautiful vintage digital delay tones with expanded creative range
- Distinctive modulation with independent Rate and Depth knobs
- Hi Cut control for shaping the high-frequency amount
- Variable Offset feature for creating unique sounds with a secondary delay line
- Adjustable maximum delay time: 800 ms (mono/stereo) or 1600 ms (mono)
- Two stereo delay options: panning and discrete stereo
- Versatile output modes: stereo, wet/dry, and dry mute (mono or stereo)
- Tap tempo and carryover functions
- Jack for extended control with up to two footswitches or an expression pedal
- TRS MIDI input for syncing to external MIDI clock signals
- BOSS five-year warranty
- Sample Rate: 48 kHz
- AD Conversion: 24 bits + AF method (Adaptive Focus method)
- DA Conversion: 32 bits
- Nominal Input Level: INPUT A (MONO), INPUT B: -20 dBu
- Maximum Input Level: INPUT A (MONO), INPUT B: +7 dBu
- Input Impedance: INPUT A (MONO), INPUT B: 1 MΩ
- Nominal Output Level: OUTPUT A (MONO), OUTPUT B: -20 dBu
- Maximum Output Level: OUTPUT A (MONO), OUTPUT B: +7 dBu
- Output Impedance: OUTPUT A (MONO), OUTPUT B: 1 kΩ
- Recommended Load Impedance: OUTPUT A (MONO), OUTPUT B: 10 kΩ or greater
Specifications
CONTROLS
- TIME knob
- FEEDBACK knob
- LEVEL knob
- DEPTH knob
- RATE knob
- HI CUT knob
- OFFSET Knob
- Pedal switch
- CARRYOVER switch
INDICATOR
- CHECK indicator (Used for indication of Tempo and check battery)
CONNECTORS
- INPUT A (MONO) jack, INPUT B jack, OUTPUT A (MONO) jack, OUTPUT B jack: 1/4-inch phone type
- CTL/EXP jack: 1/4-inch TRS phone type
- DC IN jack
- MIDI IN jack: Stereo miniature phone type
POWER SUPPLY
- Alkaline battery (9 V, 6LR61 or 6LF22, commercially available)
- AC adaptor (PSA series: sold separately)
CURRENT DRAW
- 75 mA
EXPECTED BATTERY LIFE UNDER CONTINUOUS USE
- Alkaline: Approx. 4.5 hours
- *These figures will vary depending on the actual conditions of use.
