Product Information
From sublime cleans to the gnarliest of Metal tones, your performance demands the pinnacle in tonal excellence.
Enter ReVolt Guitar, a forward-thinking all-analog 3-channel preamp primed to serve as the beating-heart of your rig. The latest-iteration of Two notes’ critically- acclaimed preamp solutions has been engineered with a singular mission: to empower players with the ultimate in foundation tone.
Forget any preconceptions of a run-of-the-mill amp-in-a-box: ReVolt Guitar stands-apart. It’s inspired by a trio of iconic amps; It’s fuelled by 200V and genuine tube power; It’s born to assimilate into a myriad of usage scenarios; It cuts above the rest with its integrated OD-Boost circuit.
Specifications
Input / Output
Input:
Jack 6.35 mm (1/4”) unbalanced (TS, Tip/Sleeve)
Impedance : 1 MOhms
Send:
Jack 6.35mm(1/4“) unbalanced (TS)
Max output level : +11dBu
Impedance : 300 Ohms
Return:
Jack 6.35mm(1/4“) unbalanced (TS)
Max input level : +11dBu
Impedance : 1 MOhms
Unbuffered, directly connected to Output when active
Output:
Jack 6.35 mm (1/4”) unbalanced (TS)
Max output level : +11 dBu
Impedance : 300 Ohms
DI Output:
XLR, balanced
Impedance : 600 Ohms balanced, 300 Ohms unbalanced
Max output level : +11dBu
Protected against +48V phantom power
Phones:
Jack 3.5 mm (1/8“) stereo (TRS, Tip/Ring/Sleeve)
Impedance : 39 Ohms
Aux In:
Jack 3.5 mm (1/8“) stereo (TRS, Tip/Ring/Sleeve)
Impedance : 10 kOhms
Preamp
Tube:
PSVANE ECC83
Boost Circuit:
+0 dB to +20dB, centered around 1.1 kHz
Power
Mains power adaptor:
DC Jack 2.1mm, negative center
Input voltage:
12V DC
Power consumption:
Approx. 6W
Current draw:
500mA
Dimensions & weight PROVISIONAL
Width x Depth x Height*:
19.2cm x 11.7cm x 7.2cm – 7.6″ x 4.6″ x 2.8″
*Including connectors and knobs
Weight:
750 g / 1.65 lbs
Warranty
2 Years WarrantyShipping & Delivery
